PICO-8 User Manual
PICO-8 is built with:
Lua 5.2 http://www.lua.org // see license.txt
ws281x by jgarff // see license.txt
libb64 by Chris Venter
miniz by Rich Geldreich
Latest version of the OG manual (as html, txt) and other resources:
▨ Welcome to PICO-8!
PICO-8 is a fantasy console for making, sharing and playing tiny games and other computer programs. When you turn it on, the machine greets you with a shell for typing in Lua programs and provides simple built-in tools for creating sprites, maps and sound.
The harsh limitations of PICO-8 are carefully chosen to be fun to work with, encourage small but expressive designs and hopefully to give PICO-8 cartridges their own particular look and feel.
Display: 128x128, fixed 16 colour palette
Input: 6-button controllers
Carts: 32k data encoded as png files
Sound: 4 channel, 64 definable chip blerps
Code: Lua (max 8192 tokens of code)
Sprites: Single bank of 128 8x8 sprites (+128 shared)
Map: 128x32 8-bit cells (+128x32 shared)
❶ Getting Started
1.1 - Keys
ALT+ENTER: Toggle Fullscreen
ALT+F4: Fast Quit (Windows)
CTRL-Q: Fast Quit (Mac, Linux)
CTRL-R: Reload / Run / Restart cartridge
CTRL-S: Quick-Save working cartridge
CTRL-M: Mute / Unmute Sound
ENTER / P: Pause Menu (while running cart)
Player 1 default keys: Cursors + ZX / NM / CV
Player 2 default keys: SDFE + tab,Q / shift A
To change the default keys use the KEYCONFIG utility from inside PICO-8:
1.2 - Hello World
After PICO-8 boots, try typing some of these commands followed by enter:
FOR I=1,4 DO PRINT(I) END
(Note: PICO-8 only displays upper-case characters -- just type normally without capslock!)
You can build up an interactive program by using commands like this in the code editing mode along with two special callback functions
_DRAW. For example, the following program allows you to move a circle around with the cursor keys. Press Esc to switch to the code editor and type or copy & paste the following code:
X = 64 Y = 64
IF (BTN(0)) THEN X=X-1 END
IF (BTN(1)) THEN X=X+1 END
IF (BTN(2)) THEN Y=Y-1 END
IF (BTN(3)) THEN Y=Y+1 END
` FUNCTION _DRAW()
Now press Esc to return to the console and type RUN (or press CTRL-R) to see it in action. Please refer to the demo cartridges for more complex programs (typeINSTALL_DEMOS`).
If you want to store your program for later, use the
And to load it again:
This is everything that I have painfully copied and pasted.
Now you can play some example games.
