I couldn't find any pathfinding example for pico-8 that could be used for non-grid movement, so I took this one and built on top it.
The necessity came when I started writing a game that had fluid movement inside a grid map (so rather than moving one tile at a time, the characters move one pixel at a time). Even with a tile-based map system, the collisions still had to be checked again for every pixel.
This cart visually shows how the pathfinding works:
- Yellow squares: path found with the grid pathfinding.
- White line: path to the next grid tile, found with the pixel pathfinding.
You can move one of the characters using the arrows. By pressing X, you can enable/disable the visualization.
Tiles: https://thkaspar.itch.io/micro-tileset-overworld-dungeon
The strategy is:
- Use A* at a tile grid level for long-distance pathfinding to find the shortest path to the target.
- Get the closest tile to the character from the shortest path.
- Use A* again at a pixel level to find the pixel path to that tile.
Of course it'd be possible to use A* at a pixel level for the whole path, but pico-8 limitations would be hit pretty quickly on a large map with many characters.
I thought I'd post it here to help the next person who needs something similar.
Cool code though i seem to have implemented something incorrectly and it gives me out of memory cartridge attached
